10 IN. TABLE SAW PARTS MODEL NO. BT2503RN
Any attempt to repair or replace electrical parts on this Table Saw may create a HAZARD unless repair is done by a
qualified service technician. Repair service is available at your nearest Customer Service Centre.
PARTS LIST FOR TABLE SAW SCHEMATIC
PARTS LIST
I.D. NO
Description Size QTY
I.D. NO
Description Size QTY
08VH CORD CLAMP 1 293H PUSH STICK 1
0901 BUSH 1 2A48 HEX. HD. SCREW AND WASHER M5*0.8-16 9
090Q PLUNGER HOUSING 1 2GYV SLIDING BASE ASS’Y 2
09JK WRENCH 1 2H5T
CR. RE. ROUND WASHER HD. SCREW
M5*0.8-25 8
0B2B NEEDLE POINTER 1 2JHQ SLIDING BASE ASS’Y 2
0B3R WRENCH 1 2RVJ CLAMPER BRACKET 1
0B9P CLAMP 1 2RVM GEAR 1
0BA4 SPACER 1 2RVP SET PLATE 1
0BA9 SPACER 1 2RVR GUIDE CLAMP 4
0BAB SHIM 1 2RVW RETAINING CLIP 1
0BAC SET NUT 1 2RW6 SET PLATE 1
0BAE ARBOUR COLLAR 1 2SJU SPACER 1
0BAT NUT 1 2T6E CLAMP ASS’Y 1
0J3U HEX WRENCH 1 2TD0 COLLAR 1
0J4K FLAT WASHER
φ10*19-1.8
1 2TDL FLAT WASHER 1
0J52 FLAT WASHER
φ16*25-1.2
1 2TLE POWER CABLE ASS‘Y 1
0J6K FLAT WASHER
φ6*30-4
1 2TLZ POINTER BRACKET 1
0J6T FLAT WASHER
3/16*3/4-1/16
4 2V60 RIVING KNIFE 1
0J72 FLAT WASHER
1/4*5/8-1/16
1 2V70 SPECIAL BOLT 2
0J74 FLAT WASHER
1/4*5/8-3/32
1 2VXC BLADE ASS‘Y 1
0J78 FLAT WASHER
1/4*1/2-3/32
2 2WES LOCKING HANDLE ASS‘Y 1
0JAE EXTERNAL TOOTH LOCK WASHER φ4 2 2X6N SWITCH BOX ASS‘Y 1
0JAF EXTERNAL TOOTH LOCK WASHER φ5 1 2YEY BODY 1
0JB2 WAVE WASHER WW-12 1 2YGN PLATE 1
0JD1 SPRING PIN 1 2YGQ RETAINING CLIP 2
0JED C-RING 1 2YGT ANGLE ROD 1
0JEY E-RING 1 2YHT LOCKING HANDLE ASS‘Y 1
0JPJ HEX. HD. BOLT M6*1.0-40 1 2YMP MOTOR ASS‘Y 1
0JZY HEX. SOC. TRUSS HD. SCREW M6*1.0-12 1 2YSP EXTENSION WING(RIGHT) 1
0K0X HEX. HD. SCREW AND WASHER M6*1.0-16 1 2YSQ EXTENSION WING(LEFT) 1
0K0Y HEX. HD. SCREW AND WASHER M6*1.0-20 4 2YSX UPPER TUBE(BACK) 2
0K7K CR. RE. ROUND WASHER HD. SCREW M6*1.0-12 2 2YTA SUPPORTING PLATE 1
0K8C CR. RE.COUNT HD. TAPPING SCREW M4*18-10 4 2YTG RETAINING CLIP 1
0K9T HEX. HD. TAPPING SCREW M5*16-16 6 2YTL MITRE GAUGE ASS‘Y 1
0K9U HEX. HD. TAPPING SCREW M5*16-25 4 2YTU EXTENSION WING(BACK) 1
0KA4 CR.RE. PAN HD. TAPPING SCREW M4*16-16 2 2YTV DADO TABLE INSERT 1
0KBQ CR.RE. PAN HD. TAPPING SCREW M5*16-10 1 2YTW TABLE 1
0KC8 CR. RE. TRUSS HD. TAPPING SCREW M4*16-16 3 2YTY BODY SHELL 1
0KCX
CR. RE. PAN HD PLAIN WASHER TAPPING SCREW
M5*0.8-10 7 2YUQ HAND WHEEL ASS‘Y 1
0KCY
CROSS-RECESSED PAN HD PLAIN WASHER TAPPING SCREW
M5*0.8-12 8 2YUT HEIGHT REGULATING BOLT ASS‘Y 1
0KDK CR. RE. PAN HD. SCREW M5*0.8-16 1 2Z8W HAND WHEEL ASS‘Y 1
0KDR CR. RE. PAN HD. SCREW M5*0.8-10 2 2ZA3 RIP FENCE ASS’Y 1
0KF6 CR. RE. PAN HD. SCREW M4*0.7-8 2 2ZAJ STIFFENER ASS‘Y 1
0KJ0 CAP HD. SQ.NECK BOLT M6*1.0-16 1 2ZAK BEVEL ANGLE ADJUSTMENT ASS‘Y 1
0KJN CAP HD. SQ.NECK BOLT M6*1.0-35 1 2ZAU UPPER TUBE 1
0KMS HEX. NUT M6*1.0 T=5 1 2ZAV UPPER TUBE 1
0KQJ CROWN NUT
M8*1.25 T=12.5
2 2ZAW UPPER TUBE 1
0KQW LOCK NUT M5*0.8 T=5 2 2ZAX UPPER TUBE 1
0KQX NUT M6*1.0 T=6 1 2ZMC INSTRUCTION MANUAL 1
0KRQ SERRATED TOOTHED HEXAGON FLANGE NUT M6*1.0 T=6 1 2ZNN LABEL 1
0KTK STRAIN RELIEF 2 2ZNT SCALE 1
0KWU LEAD WIRE ASS‘Y 1 2ZNU SCALE 1
0LVJ SWITCH KEY 1 2ZNV SCALE 1
0LSL CIRCUIT BREAKER SWITCH 1 2ZNW SCALE 1
0LWG ON/OFF ROCKER SWITCH ASSEMBLY 1 2ZNX SCALE 1
0STF LOCATING RING ASSEMBLY 1 302W FLAT WASHER φ6*21-3 1
10K5 HEX. SOC. HD. CAP BOLT M5*0.8-8 2 30GS ANTI-KICKBACK PAWL ASS’Y 1
10LF HEX. NUT M6*1.0 T=4 2 30TM TRADE-MARK LABEL 1
212M LEAD WIRE ASS‘Y 1 30TN WARNING LABEL 1
26E8 FLAT WASHER φ5*9.5-1.2 1 31GP BLADE GUARD ASS‘Y 1
27JR HEX. SOC. SET SCREW M5*0.8-6 4 32PK SPACER 1
286B SLIDING BASE 2 3315 WORM 1
286C LOCATION SEAT 2 Z06M TABLE INSERT ASS’Y 1
WARNING
!
