– 9 –
ITEM DESCRIPTION QTY
R.
Top short leg bracket
2
S.
Top long leg bracket
2
T.
Bottom short bracket
2
U.
Bottom long bracket
2
V.
Legs
4
W.
Stand mounting hardware
1
X.
Fence storage hardware bag
1
Y.
Hooks
4
WARNING
!
● To avoid injury from unexpected starting or electrical
shock, do not plug the power cord into a source of
power during unpacking and assembly. The cord
must remain unplugged whenever you are adjusting/
assembling the saw.
● The saw is heavy and should be lifted with care.
Get the assistance of someone to lift and move the
saw.
● If any part is missing or damaged, do not attempt
to assemble the table saw, or plug in the power
cord until the missing or damaged part is correctly
replaced.
TABLE OF LOOSE PARTS
TABLE SAW
UNPACKING AND CHECKING CONTENTS
Carefully unpack the table saw and all its parts, and
compare against the list below and the illustration on the
next page. With the help of an assistant place the saw
on a secure surface and examine it carefully.
CARTON CONTENTS
TABLE OF LOOSE PARTS
STAND
ITEM DESCRIPTION QTY
A. Table saw assembly 1
B. Table extension 2
C. Rear table extension 1
D.
Rear table extension tube and
location seat
2
E. Table extension wing location screws 3
F. Blade guard assembly 1
G. Anti-kickback pawls assembly 1
H. Riving knife hardware bag assembly 1
I. Rip fence 1
J. Hand wheels assembly 1
K. Dado table insert 1
L. Mitre gauge 1
M. Hex keys 1
N. Blade wrenches 2
O. Push stick 1
P.
Blade 1
Q. Dust bag 1
NOTE: To make assembly easier, keep contents of box
together.
To Next Page
