PRODUCT DESCRIPTION AND IDENTIFICATIONS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
18
19
17
1. Battery pack
2. Front hand guard/chain brake
3. Guide bar
4. Saw chain
5. Chain tensioning dial
6. Sprocket cover
7. Battery level display on button
8. Battery level indicator
9. Main power switch bumper
10. Main power indicator
Not all the accessories illustrated or described are included in standard delivery.
11. Lock off switch
12. Rear handle
13. Switch trigger
14. Front handle
15. Oil tank cap
16. Bumper spike
17. Charger
18. Chain catcher
19. Guide bar cover
