31
Mark Description Ref. ECLI15MA* ECLI20MA* ECLI30MA* ECLI40MA*
27
Fin coil
HWX301060202502

n/a n/a n/a
HWX80600042 n/a

n/a n/a
HWX80600043 n/a n/a

n/a
HWX80600044 n/a n/a n/a

28 / / / / / /
29
16A 50Hz 5mH coil HWX82500006
  
n/a
20A 50Hz 5.2mH coil HWX82500005 n/a n/a n/a

30 Left panel
HWX80700446
  
n/a
HWX80700315 n/a n/a n/a

31 DC ventilator motor
HWX80200018
  
n/a
HWX20000330132 n/a n/a n/a

32 Printed circuit board Driver
HWX82300052
  
n/a
HWX82300007 n/a n/a n/a

33
230V/12VDC transformer
HWX82600008
   
34 Terminal block L-N-GND -5 connections 4mm² HWX40003901
   
35 K2 relay HWX20000360297
   
6. APPENDIX (continued)
(*) Check the machine references on the conversion table (see label on the cover of the manual).
