Overview
Specifications
Plumbing diameter: 2½" unions
Input power (corded model): 120VAC, 50Hz/60Hz
Input power (hardwired model): 120VAC, 50Hz/60Hz or 240VAC, 50Hz/60Hz
Power consumption: 151 Watts; or 1.26A, 120 VAC; 0.66A, 230VAC
Maximum operating pressure: 50 psi
Operating flow range: 10-120 gpm
Maximum flow rate: 120 gpm
99.9% sanitization flow rate maximum: 80 gpm
Sizing
The HydraPure is capable of sanitizing residential pools up to 60,000 gallons. For larger installations,
more than one HydraPure can be used. When using multiple HydraPure units, plumb vessels in paral-
lel.
Tools Needed
Saw or PVC pipe cutter
PVC glue
Philips head screwdriver
Installation
Before starting your installation, you MUST read this manual in its entirety in order to install your unit
in a safe manner. Note that a few moments spent becoming familiar with the HydraPure unit and
its installation may save a great deal of time (and expense) later. If you have any questions that are
unanswered when you have completed the reading of this manual, contact your supplier or Hayward.
Installation of HydraPure requires mounting, plumbing, installing a venturi and flow switch (on the
return side of the filter pump), and connecting the required electrical connection. Disconnect power to
the pool filter pump before starting this installation. Installation must be performed in accordance with
local and NEC code.
Determine a Suitable Location
The HydraPure must be mounted at least 5' from the pool (more, if local codes require). The Hydra-
Pure should be installed after all equipment (pump, filter, heater) but prior to any chlorinators (salt cell,
tablet feeder, liquid injection).
3
