UV Lamps Replacement
WARNING: Turn off all power to the HydraPure unit and pool pump. Before proceeding allow at least
15 minutes for the lamp(s) in the unit to cool. Never remove the electrical enclosure cover without first
disconnecting the power source from the HydraPure unit. Never remove the HydraPure unit’s cover
without turning off the pump. Before removing lamps, you must wear protective rubber gloves and
safety eye wear. Do not handle a hot lamp or serious burns will occur.
Red flashing UV BULB LIFE indicates UV bulb is no
longer sanitizing and should be replaced soon,
2
Remove screws to lid.
3
Remove single
screw to electrical
enclosure cover.
4
Disconnect UV
lamps from ballast.
5
Remove spring clip.
1
Turn Off Power to unit or unplug.
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
12
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
