Installation
Page 6
Connect hoses as
shown
Leader hose is
connected to the
Cleaner head
1. Starting with the leader hose, connect the four foot hose sections
until they reach eight feet (two hose lengths) past the furthest point
Note: Although 10 hoses section are provided, the installation may require more.

Hayward Navigator Pro Specifications

General

Pool Type	In-ground
Warranty	2 years
Hose Diameter	1.5 inches
Pool Surface Compatibility	Concrete, Vinyl, Fiberglass
Hose Length	40 feet
Power Source	Pool's filtration system
Type	Suction-side pool cleaner
