Hayward Flow Control www.haywardflowcontrol.com 1-888-HAY-INDL (1-888-429-4635)
TCIS Rev D 5/15/18
Pg. 10 of 11
6.0 PARTS LIST:
END CONNECTOR
O-RING (2)
END CONNECTOR (2)
ASSY NUTS (2)
BALL
SEAL RETAINER
O-RING
SQUARE CUT SEAL
SEAL RETAINER
BODY
