Hayward TriStar SP3200 Series User Manual

USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
TriStar Variable Speed Pump
Page 11
18
17
16
15
1210
9
8
7
14
13
11
3
5
4
6
1
2
19
16
20
TriStar VS Pump - Replacement Parts
Parts Diagram
Parts Listing
Ref. No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
--
--
--
Part No.
SPX3200UNKIT
SPX3200UG
SPX3200A
SPX3200DLS
SPX3200S
SPX3200M
SPX3200Z8
SPX4000Z1
SPX3200B3
SPX3200Z1
SPX3021R
SPX3210C
SPX3215C
SPX4000SA
SPX3200T
SPX3200E
SPX3200Z211
SPX3200Z3
SPX3200Z5
SPX4000FG
SPX3200GA
SPX3210VSM
SPX3215VSM
SPX3200Q
Description
Union Connector Kit (Includes Union Nut, Connector, Gasket - 2 ea.)
Union Gasket
Pump Strainer Housing, 2” x 2½” with Drain Plugs, threaded style
Strainer Cover Kit (Includes Strainer Cover, Lock Ring, O-Ring)
Strainer Cover O-Ring
Strainer Basket
Diffuser Screw
Diffuser O-Ring
Diffuser
Impeller Screw
Impeller Ring
Impeller to suit SP3210VS
Impeller to suit SP3215VS
Shaft Seal Assembly
Housing O-Ring
Seal Plate
Housing Insert/Seal Plate Spacer Kit
Housing Bolt
Motor Bolt
Drain Plug with O-Ring
Bracket, Motor Support TriStar
Motor, suit SP3210VS
Motor, Suit SP3215VS
Adaptor - Motor Support - use on SPX3200GA in Australia - Not Shown
Qty. Req’d
1
2
1
1
1
1
2
1
1
1
1
1
1
1
1
1
6
6
4
2
1
1
1
1

Hayward TriStar SP3200 Series Specifications

General

Horsepower	1.5 HP
Voltage	115/230V
Port Size	2 inch
Phase	Single Phase
Warranty	1 Year
Wet End Material	Thermoplastic
Model	SP3200
Type	Centrifugal
Union Connection	2"
Seal Type	Mechanical Seal
