Assembly
1.
Screw handles
(A,
Fig.02)
onto
handwheel (8,
Fig.3) and tighten.
2. Repeat for remaining handles of table.
Installation
,&.
WARNING!
Machine is heavy! Use an appropriate lifting
device and use
extreme
caution when moving the
machine to its final, location.
Fallure to comply'may cause serfous lnjuryl
1 . The
location for
the mill/drill should be
well
lit, dry,
and have room enough to allow the head to rotate
360
°
.
2. Carefully lift the mill/drill with properly rated
equipment to a sturdy stand or working bench.
For best performance, through boit the mill/drill to
a stand.
We do not
recommend that unattached machines be
operated,
as
the machine will move during operation!
3. Before bolting the mill/drill to a bench or stand, the
unit must be level in both directions. Place a level
on the table in both directions.
4. If the table of mill is not to level, shim under the
low corner(s) until level. Tighten the fastening
bolts. Check for level again. Adjust as necessary
until the mill/drill is level. Check again when
securing bolts are tightened.
Installation
Drawing
(Fig. 03)
The installation drawing described below may differ
from the real dimensions. The tolerances are in the
range of the general tolerances according to OIN
7168.
- 7 -
Fig.
02
220
Fig. 03
315
60
8
To Next Page
