HBM T40FH - Page 55

Dimensions
T40FH A4429-3.0 HBM: public 53
Dimensions in mm (1 mm = 0.03937)
Dimensions without tolerances, per
DIN ISO 2768-mk
230
(150)
40
40
112
12
M36
Ø37
12
10
Ø540
Ø470
Ø540 Ø470
Ø350
Ø345 g6
()
344.982 344.946
Ø345 H7 ()
345.057 345.000
27
53
490
16
44
102.5
95
Height of
rotational
speed
sensor
Height of
housing
Partial sections
cut A-A
2.5
