HBM T40FH - 13.2.1 T40 FH 100 Knm - 150 Knm; Option 4, Code PNJ; T40 FH Torque Transducer (Non-Rotating)

Dimensions
54 A4429-3.0 HBM: public T40FH
13.2 T40FH torque transducer (non-rotating),
Option 4, Code PNJ
13.2.1 T40FH 100 kNm - 150 kNm
22.5°
16x22.5°=360°
Ø395
A
A
M30
184
(120)
32 32
76
10
B
Ø450
Ø450
Ø260 g6
()
259.983 259.951
Ø260 H7 ()
260.052 260.000
Partial sections
cut A-A
12
B
Dimensions in mm (1 mm = 0.03937)
Dimensions without tolerances, per DIN ISO 2768-mk
