8
T4A, T4WA-S3
3 Electrical connection
T4A torque/ screw torque transducers are delivered complete with one
3m–long, unterminated connection cable. The T4WA-S3 versions are
delivered complete with two such cables.
NOTE
If you require a plug assembly, please be sure to specify the measuring
amplifier type, and for system devices also specify the connection board
you are using.
3.1 T4A pin assignment (torque)
Wire colour Function
White (wh) Measurement signal torque (+)
Black (bk) Excitation voltage (–)
Blue (bu) Excitation voltage (+)
Red (rd) Measurement signal torque (–)
Yellow (ye) Cable shield to housing ground
3.2 T4WA-S3 pin assignment (torque)
Wire colour Function
White (wh) Measurement signal torque (+)
Black (bk) Excitation voltage (–)
Blue (bu) Excitation voltage (+)
Red (rd) Measurement signal torque (–)
Grey (gy) Sensor circuit (–)
Green (gn) Sensor circuit (+)
Yellow (ye) Cable shield to housing ground
