HCL HCM9LWAN21 - Monitor Exploded View

19"W LCD Color Monitor HCL HCM9LWAN21
37
10. Monitor Exploded View
No.
1
2
3
4
5
6
7
8
9
11
12
13
1
15
16
1
18
10
BEZEL(L9W05-A2)
THERMAL PAD
PANEL-SIDE-BRACKET
PANEL
MAIN BOARD
INVERTER BOARD
SHIELD
MYLAR
CLAMP
STAND
HINGE BRACKET
RUBBER
MAINFRAME
MYLAR
REAR COVER
HINGE
BASE
RUBBER FOOT
Description
No.
Description
