19"W LCD Color Monitor HCL HCM9LWAN21
4
1. Monitor Specification
Driving system TFT Color LCD
Viewable Image Size
481mm diagonal
Pixel pitch 0.2835mm( H ) × 0.2835mm( V )
LCD Panel
Video R,G,B Analog Interface
Separate Sync. H/V TTL
H-Frequency 30kHz – 83kHz
Input
V-Frequency 55-75Hz
Display Colors 16.7M Colors
Dot Clock 135MHz
Max. Resolution 1440 × 900 @60Hz
Plug & Play VESA DDC 2B
TM
EPA ENERGY STAR
®
ON Mode ≤36W
OFF Mode ≤2W
Input Connector 15-pin D-Sub
Input Video Signal Analog:0.7Vp-p(standard), 75 OHM, Positive
Horizontal : 410mm
Maximum Screen Size
Vertical : 256mm
Power Source 100~240VAC,47~63Hz
Operating Temp: 5° to 50°C
Storage Temp.: -20° to 60°C
Environmental Considerations
Operating Humidity: 10% to 85%
Dimension 440×356×215 (W ×H×D)mm
Weight (N. W.) 4kg Unit (net)
Power Consumption ( Maximum ) 36 Watts
Regulatory Compliance UL, CE, FCC
