Page 5
---------------------
Unpack the kit and check each part against the following list. Any part that
is packed in an individual envelope with the part number on it should be
placed back in the envelope after you identify it until all parts are accounted
for.
The key numbers correspond to the numbers on the "Parts Pictorial" in the
separate "Illustration Booklet" on Page 1.
Each circuit part in this kit has its own "Circuit Component Number" (R1,
CZ,D101, etc.J..This is a specific number for only that one part. The purpose
of these numbers is to help you identify the same part in each section ofthe
Manual.
To order a replacement part: Always include the PART NUMBER. Use the
Parts Order Form furnished with the kit. If one is not available, see "Re-
placement Parts" inside the rear cover of the Manual. Your Warranty is
located inside the front cover. For prices, refer to the s~parate "Heath Parts
Price List."
KEY
HEATH
No. Part No.
CIRCUIT
Compo No.
NOTE: The following resistors are 1/4-watt, 5% tolerance unless otherwise
noted.
KEY
HEATH
No. Part No.
CIRCUIT
Compo No.
4 560
n
(green-blue-brown)
2 1000
n
(brown-black-red)
6-561-12
6-102-12
R2, R4, R8,R9
R18, R22
To Next Page
