Heathkit mMATIC SA-5010A User Manual

- 31 -
DIODES
MAY BE REPLACED
WITH
CIRCUIT COMP. NO.
IDENTIFICATION
1N4149
GD510
DRS110, 1N5399
1N4002
D1, D5, D6, D7, D13
D2, D3, D4
D201, D202
D8, D9, D11, D12
TIL209
D101...D105
TRANSISTORS
MAY BE REPLACED
WITH
CIRCUIT COMP. NO.
IDENTIFICATION
2N4121
MPSA42
MPSA20
MPSA05
MPSA55
MPSA93
Q6, Q15
Q14
Q1...Q5, Q7, Q11, Q12, Q101
Q17
Q8, Q9, Q13, Q18
Q16
INTEGRATED CIRCUITS
MAY BE REPLACED
WITH
CIRCUIT COMP. NO.
IDENTIFICATION
7805
U4
78L05
U5
