• We recommend save the package for future use. The packaging materials must still be
recycled or disposed of in compliance with the relevant legislation. Sort different parts of
the packaging according to material and hand it to the appropriate collection sites. For
further information contact your local administration.
PACKAGE CONTENTS
1x lawn mower body, 1x upper part of the handle, 1x lower part of the handle, 1x grass bag, 1x
metallic frame of grass bag, 1x set of fasteners, 4x wheel, 1x manual for use
• Standard accessories are subject to change without notice.
• This product requires assembly. The product must be assembled correctly before use.
ASSEMBLY
The complete push bar, the grass catcher and the wheels must be assembled before using
the lawnmower. Follow the operating instructions step-by-step and use the pictures provided as
a visual guide to easily assemble the machine.
1. Put the metallic frame inside the grass catcher (fig. 2) - if not already assembled.
2. Fix the bag on the metallic frame (fig. 3).
3. Screw the lower part of the handle to the chassis of the mower (fig. 4A).
4. Screw the upper part of the handle to the lower part of the handle (fig. 4B). Do not forget
to the right side of the grip insert holder of the handle of the starter.
5. Remove the handle of the brake and to the hole in it hook extension of the cable brake
(fig. 5), then return the handle back into the grip.
6. Attaching the wheels (fig. 7-8): Use an wrench on the bolts and secure four wheels to
the deck in the appropriate position (fig. 6) - if not already mounted.
C NOTE! The pack contains bolts for the left and right side of the lawnmower - LH =
left, RH = right (fig. 9) - please pay attention to install.
Note: I RH = Clockwise rotation / LH = Counterclockwise rotation.
7. Mount the small washer between wheel and deck. Use corresponding holes when attaching
all four wheels.
8. Tighten the bolts. Put wheel cover.
9. Attach the cable using the cable-clamp (fig. 10).
MOUNTING AND DISMOUNTING THE GRASS CATCHER
1. To fit: Raise the rear cover and hitch the grass catcher on rear of mower (fig. 11).
2. To remove: grasp and lift rear cover, remove grass catcher.
STARTER HANDLE
1. Disconnect the spark plug boot.
2. Press stop control handle. Pull gently the starter handle toward the handle and put it to
the rope guide (fig. 12).
3. Connect the spark plug boot.
