ABC Introduction
Suprasetter 74/105 – Operation 1–1
1 Introduction
Description of the Unit and its Functions
The Suprasetter 74/105 is a high-speed, PostScript™-
compatible, computer-to-plate imaging device.
It images thermal printing plates in daylight opera-
tion.
The Suprasetter 74/105 receives screened data from
the RIP for imaging onto printing plates. The printing
plates are placed manually on the insertion table or
loaded by the Single Cassette Loader. The Suprasetter
74/105 automatically loads the printing plate onto
the drum, images it, punches it (option) and then
transports the imaged plate back to the insertion
table or, if an online processor is connected, directly
to the processor.
Insertion table
On/Off button
Power switch
Status LEDs
Load buttons
