● Test
of the power-off condition in case of a short-
circuit (Z
L-N
)
For these measurements, connect the charging cou‐
pler to a test adapter for vehicle simulation in accor‐
dance with EN 61581-1. The measurements must be
carried out with the adapter in the C mode. Carry out
the measurements on the measuring sockets of the
test adapter. The values must comply with those of the
selected circuit breaker.
● Test of the power-off condition in case of a fault
(Z
L-PE
)
For these measurements, connect the charging cou‐
pler to a test adapter for vehicle simulation in accor‐
dance with EN 61581-1. The measurements must be
carried out with the adapter in the C mode. Carry out
the measurements on the measuring sockets of the
test adapter with a suitable instrument. The values
must comply with those of the selected circuit breaker.
● Test of the integrated DC residual-current detec‐
tion
For these measurements, connect the charging cou‐
pler to a test adapter for vehicle simulation in accor‐
dance with EN 61581-1. The measurements must be
carried out with the adapter in the C mode. Carry out
the measurements on the measuring sockets of the
test adapter with a suitable instrument. If the residual
current is greater than 6 mA DC, the charging system
must disconnect the charging coupler from the power
supply. The fault indicator on the charging system
must be activated.
● Test of the upstream RCD
The upstream RCD has to be checked at the connec‐
tion point of the charging system supply in the build‐
ing's electrical cabinet. The RCD must trip in accor‐
dance with the national regulations.
1.6 Specifications
Designation Technical specifications
Regulations IEC 61851-1; IEC61439-7
Charging capacity type 3 up to 11 kW
Nominal voltage 230 V / 400 V / 1/3 AC
Nominal current up to 16 A
adjustable from 6 A to 16 A in 2 A increments
Nominal frequency 50 Hz
Data interface RS485
Charging connection/charging coupler Type 2
Length of charging cable 5 m or 7.5 m
Status information Front illumination
Safety instructions
A.1.6 00.999.3046/
