140 II Technical Information
II – 6 Specifications for Milling
Data interface Serial:
RS-232-C/V.24 300 to 115 200 baud
For output of programs, measured values and parameters;
For input of programs and parameters
Parallel:
Centronics for output of measured values
Switching inputs/outputs Upon request (via separate AMI input/output unit)
Accessories Tilting base
Remote console
KT 130 Edge Finder
Main power input 100 V to 240 V (–15% to +10%) 50 Hz to 60 Hz (±3 Hz); power consumption 35 W
Operating temperature 0 °C to 45 °C (32 °F to 113 °F)
Degree of protection (EN 60529) IP 40 (IP 54 front panel)
Weight 3.2 kg
POSITIP 880 Data
