8.7 Coordinate Transformation Cycles
5 Setting the datum
■
Manually by touching the workpiece with the tool in the non-tilted
coordinate system (see section 2.4 “Setting the Datum Without a
3-D Touch Probe”)
■
Automatically by using a HEIDENHAIN 3-D touch probe (see the
new Touch Probe Cycles Manual, chapter 2)
6 Start the part program in the operating mode Program Run,
Full Sequence
7 Manual Operation mode
Use the 3D-ROT soft key to set the function TILT WORKING PLANE
to INACTIVE. Enter an angular value of 0° for each axis in the menu
(see section 2.5 “Tilting the Working Plane”).
