CHAPTER 12 TECHNICAL SPECIFICATIONS
193
Focal Length: 12.5 mm
Iris Range: F/1.4 to C
Temperature Range: -20°C to +50°C
12.2.8 K6-MAX/M and K7-MAX/M
Design: mounting set IMAG-K6 or IMAG-K7
camera on IMAG-MAX/L or IMAG-
MAX/LR. Consisting of camera holder and
metal rod 15 cm length, 15 mm diameter.
12.2.9 Mounting Stand with Eye Protection IMAG-MAX/GS
Design: Aluminium frame featuring two clamps for
mounting LED-Array Illumination Unit
IMAG-MAX/L or IMAG-MAX/LR; red
perspex sliding hood for eye protection;
removable bottom part
Sample position: Detached leaves, slides or petri dishes
resting on x-y stage for variable
positioning; special frame for defined
positioning of multiwell plates; after
removal of bottom part, possibility to jack
up whole Mounting Stand for study of
plants in pots or trays
Dimensions: 23.5 cm x 24.5 cm x 22.5 cm (L x W x H)
Weight:
3.1 kg
