Heinzmann Programmer 2 User Manual

4 Starting the Engine
Programmer PG 02 17
- Preset PID-values:
Number Parameter Value Unit
100 Gain 15 %
101 Stability 10 %
102 Derivative 0 %
- Parameterize the absolute limits of actuator travel:
Number Parameter Value Unit
310 ActPosSecureMin 3 %
312 ActPosSecureMax 97 %
- Adjust starting actuator position (type 1):
Number Parameter Value Unit
250 StartType 1
251 LimitsDelay 3 s
255 StartSpeed1 10 rpm
256 StartSpeed2 400 rpm
260 StartFuel1 60 %
- Save values to the governor's memory and reset the governor.
5. Check speed pickup and determine starter speed.
- Operate the engine stop switch so that the engine cannot be started.
Indication:
Number Parameter Value Unit
2810 SwitchEngineStop 1
In case of a failure of the speed governor system or with a wrong
parametrizing the engine can go into overspeed!
Before the start of the engine therefore the function of the separate
overspeed protection must be guaranteed.
