HELI CPCD140 - Page 11

10
Item Unit CPCD160-CU-06I
Rated Load kg 16000
Load Centre mm 600
Standard Lift Height mm 4000
Mast Tilt (fwd/bwd) deg 15/12
Wheelbase mm 3650
Tread (fwd/bwd) mm 1885/2100
Overhang (fwd/bwd） mm 1040/900
Overall Width mm 2560
Overall Length (with Fork) mm 7510
Overall Height (at Mast) mm 3800
Min. Under clearance (at Mast) mm 250
Min. Turning Radius mm 4970
Fork Size mm 1820×250×100
Fork Space mm 900-2150
Max. Travel Speed
(loaded/unloaded)
km/h 30
Max. Lifting Speed
(loaded/unloaded)
mm/s 400/330
Max. Traction Force
(loaded)
kN 105
Gradeability (loaded) % 28
Weight (with oil and water) kg 24000
Front 12.00-24-20PR
Performance & Outline Dimensions
Tyre
Rear 12.00-20-20PR
Type Cummins6BTA5.9
Rated Power / Rated
Speed
kW/rpm 138/2400
Max. torque / Rotate
Speed
Nm/rpm 757/1500
Engine
Diesel
Output L 5.88
