Ⅱ. Primary Parameter of Forklift Truck
Primary Parameter of Forklift Truck
Item Unit CPCD140 CPCD150 CPCD160-CU2 CPCD160-CU1
Rated Load kg 14000 15000 16000
Load Centre mm 900 1200
Standard Lift Height mm 3000
Mast Tilt (fwd/bwd) deg 6/12
Wheelbase mm 3650 4000
Tread (fwd/bwd) mm 1885/2100
Overhang (fwd/bwd） mm 1040/900
Overall Width mm 2560
Overall Length (with
Fork)
mm 7410 8380
Overall Height (at Mast) mm 3300
Min. Under clearance (at
Mast)
mm 250 320
Min. Turning Radius mm 4970 5600
Fork Size mm 1820×250×100 2440×250×100
Fork Space mm 900-2150
Max. Travel Speed
(loaded/unloaded)
km/h 30
Max. Lifting Speed
(loaded/unloaded)
mm/s 400/330 390/320
Max. Traction Force
(loaded)
kN 105
Gradeability (loaded) % 28
Weight (with oil and
water)
kg 22500 23000 23500 25000
Front 12.00-24-20PR
Performance & Outline Dimensions
Tyre
Rear 12.00-20-20PR
Type Cummins6BTA5.9
Rated Power /
Rated Speed
kW/rpm 138/2400
Max. torque /
Rotate Speed
Nm/rpm 757/1500
Engine
Diesel
Output L 5.88
