9. Hoist System
The main specifications see table：
Model CPCD140～160-Cu
Mast type 2-stage telescopic mast, Rolling type, C-shaped outer mast,
C-shaped inner mast
Cross Section of Inner Mast
Cross Section of Outer Mast
Max. Lift Heiget(S.T.D)
3000 mm（standard）-6500mm
Foreward Tilt 6°、5°、3°
Backward Tilt 12°、10°、6°
O.D.of End Rollers 240mm
Rollers
O.D.of side Rollers
90mm
Lift Chain LH3244、4X4、P=50.8
Fork Lifting Method
Hydraulic
Mast Tilting Method Hydraulic
Fork Spacing Adjustment Hydraulic
