HELIX HXA 40 User Manual

AUDIOTEC FISCHER GMBH · Gewerbegebiet Lake II · Huenegraeben 26 · D-57392 Schmallenberg
Tel.: 0 29 72-97 88 0 · Fax: 0 29 72-97 88 88
E-mail: info@audiotec-fischer.com · Internet: www.audiotec-fischer.com
Technical Specifications:
Cont. Power rating at 4 Ohm p. channel 4x60/80 Watts RMS/Max. Power
Cont. Power rating at 2 Ohm p. channel 4x90/125 Watts RMS/Max. Power
Cont. Power bridged into a 4 Ohm load 2x180/250 Watts RMS Max. Power
Frequency Response 20Hz-20kHz,+/-0,2dB
Total Harmonic Distortion (THD) <0,009%
TIM Distortion <0,016%
Signal to Noise Ratio >100dB
Input Impedance 10kOhm
Input Sensitivity 350mV-8,5V
Fuse 30 Ampere
Dimensions (HxWxD) in mm 31,5x218x295
Weight net 2,4kgs
HXA 40 Switchable Frequency Crossover Highpass/Lowpass 90Hz
and Full Range
HXA 40X Adjustable Crossover Frequency range 15Hz-5000Hz HP/LP
Also to use for bandpass

HELIX HXA 40 Specifications

General

Brand	HELIX
Model	HXA 40
Category	Amplifier
Language	English
