3. Start the bridge moving by pressing the function keys ``UP´´ or ``DOWN´´ for a short time.
To stop the bridge at the selected position press the function keys ``UP´´ or ``DOWN´´ again.
The fine tuning of the position can be done with the ``UP´´ and ``DOWN´´.
Attention: Always finish positioning the bridge in the same direction you started programming in.
4. Save the chosen position by pressing the function key ``GO/SET´´ again.
5. ``P´´ in the display is shown and the highest available number for a position is suggested
in the display. If necessary choose a lower number by pressing the function key ``UP´´ or ``DOWN´´.
Selecting a lower number is equal to inserting a position between already programmed positions. This implies
That all programmed positions above the point of insertion is incremented by one position number.
6. Save the chosen number by pressing the function key ``GO/SET´´ again.
7. Finish by calibrating the bridge. See section 6B.
Special feature: Please note, that when a position/stop is set, a 180 degree position/stop, from current
position, is automatically set. You can go to the automatically 180 degree set position, by pressing the
function key Go/set again, when positioned at the desired track.
NOTE: It is not possible to make a position directly at the ``zero point´´.
Also please note that it is only possible to set track positions via the Control box.
Note: If you accidentally push the ``GO/SET´´ when you wish to stop at a desired position,
the display flashes with a suggested position number. Press ``ESCAPE´´. The bridge stops and
the display shows ``Prog´´ .Push ``GO/SET´´ and then the ``UP´´ or ``DOWN´´ function keys
twice and find the correct position. Always stop with ``UP´´ function key.
Please note: The program does not allow to leave out a number for a stop. Example:
You have already four stops (which have been assigned the numbers 1 to 4)
You want to set a new stop (the fifth)
Either no. 5 (which is suggested automatically)
Or a lower no. (1, 2, 3, 4)
In case you choose a lower number (e.g. no. 2) the program automatically renumbers the stops
As shown below:
NOTE: Positions 1 and 2 (are related to the zero point) are not programmable positions; start with track 3 when
you program tracks. When you have made minimum 2 new stops, you are able to remove the
pre-installed position 2. Also please note that it´s not possible to make a position directly at the ``zero point´´.
Old stops
New stop
---
43
2
1
Stop numbers before setting the fifth stop
43
2
1
5
1
4
3
5
2
Stop numbers when setting the suggested
number for the new fifth stop
Stop numbers when choosing the no. 2 for
the new (fifth) stop
