9
BYPASS VALVE OPERATION
COMPLETE BYPASS, PART #101325
ProMate
®
Filter Valve Option
Filter Drain Line
Filter Tank Bypass
Filter Tank Outlet
3/8” Bleed-O Drain Line
1” Check Valve
(Installed Vertically)
Aeration Tank Inlet
Aeration Tank Bypass
Solenoid Vent (1/4” line
to atmospheric drain)
Filter Tank
Inlet
Aeration
Tank Outlet
Air Pump
