2412MHz~2469MHz
Power Adaptor
Parent Unit: Input: 100-240VAC 50/60Hz
Output: 5V DC 1A
Camera Unit: Input: 100-240VAC 50/60Hz
Output: 5V DC 1A
Operation
environment
Up to 1000ft (300m) outdoor (line of sight)
Up to 165ft (50m) indoor
Operating Range
Display
5.0'' Diagonal TFT LCD
Battery (Parent Unit)
Battery Life
Li-ion 3.7V 2000mAh (7.4Wh)
Up to 8 hours
RelativeHumidity:15%-85%
Maximum power
<19dBm
8.6 LANGUAGE SETTING
1. Press the MENU key then the menu will pop up;
2. Press the◀ / ▶ / ▲ / ▼ key until the language icon is selected by red box.
3. Press key enter into sub-menu, then press ◀ / ▶ / ▲ / ▼ key to select the language
you need;
4. Press key to confirm;
5. Press key to Exit.
No reception on the
monitor
Interference or poor
reception
* The power adapters may not be properly connected;
* Confirm that the camera and monitor are ON;
* Camera may be far away from the monitor;
* Camera and monitor may not be properly paired; follow PAIRING instructions;
* Move the monitor close to the camera;
* The camera or monitor may be placed too close to many metal objects;
* Other electronic devices may be interfering with the signal;
* The battery power may be too low;
Operation Temperature: +32F~+104F (0℃~40℃)
Battery Charging Temperature: +50F~+104F(10℃~40℃)
7
service@hellobabyfamily.com
9. TECHNICAL DATA
Frequency
10. TROUBLE SHOOTING
