Helmholz PN/EtherNetIP Coupler User Manual

QuickStart Guide PN/EtherNetIP Coupler | Version 3 | 13.08.2020 11
8 Status and control via the PLC
8.1 Status
The PN/EtherNetIP coupler provides a status (2 bytes) via the PROFINET input image:
Byte/Bit 7 6 5 4 3 2 1 0
Byte 0
PROFINET
Configuration
available
-
PS 1
supply
active
PS 2
supply
active
MQTT
Connection
to broker on
X1
MQTT
Connection
to broker on
X2
EtherNet/IP
IP address
available
EtherNet/IP
cable
detected
Byte 1
Number of active EtherNet/IP connections
8.2 Control
The PN/EtherNetIP coupler can be controlled via the following control bits (1 byte) in the PROFINET
output image
Byte/Bit 7 6 5 4 3 2 1 0
Byte 0
- - - - - -
EtherNet/IP
Reset
Disable
EtherNet/IP
connections
