QuickStart Guide PN/EtherNetIP Coupler | Version 3 | 13.08.2020 13
10 Technical data
Order no. 700-160-3EN02
Article designation PN/EtherNetIP Coupler
PROFINET interface
Connection 2x RJ45, integrated switch
Protocol PROFINET IO Device as defined in IEC 61158-6-10
Transmission rate 100 Mbit/s full duplex
I/O image size max. 1024 Byte of input/output data
Number of configurable slots 300
Features
PROFINET Conformance Class B (in preparation), media redundancy
(MRP-Client), automatic addressing, Topologieerkennung (LLDP, DCP),
EtherNet/IP Schnittstelle
Connection 2x RJ45, integrated switch
Protocol
EtherNet/IP; implicit messaging (Transport Class 1); explicit messaging
Transmission rate 10/100 Mbit/s, full-/half duplex
I/O image size 3x Input assemblies + 3x Output assemblies, max. 1024 Bytes data
Status indicator 9 LEDs function status, 8 LEDs Ethernet-status
Voltage supply DC 24 V (18 - 28 V DC)
Current draw max. 210mA
Power dissipation max. 5 W
Dimensions (D x W x H) 35 x 58 x 72 mm
Weight approx. 135 g
Certifications
CE, PROFINET Conformance Class B (in preparation)
Protection rating IP 20
Relative humidity 95% non-condensing
Mounting position any
Ambient temperature 0° C to 60° C
Transport and storage temperature -20° C to 80° C
