V104s GPS Compass User Guide
19
Pole mounting instructions for V104s (Outside Pole)
Required tools: 5 mm Allen key for M6 screws and adjustable wrench to
tighten jam nut
1. Place the jam nut on the pole followed by the 1” (25.4mm) adapter
base. Hand tighten the base to the desired orientation.
2. Adjust the jam nut to secure the orientation.
3. Run the cable throughout the vessel making sure to leave enough
slack to mate the NMEA 2000 cable to both the NMEA 2000
backbone and the V104s unit.
4. Run the NMEA 2000 cable through the opening in the side of the
pole mounting adapter. And then connect the mating end of the
cable to the V104 connector located on the bottom of the unit.
5. Insert the base adapter into V104s by placing the tongue of the base
into the groove of the V104s unit. When the tongue is properly
seated in the groove, the rest of the base can be pressed into place
to create a smooth seam between the base and V104s unit.
6. Use 5 mm Allen key to fasten two M6 screws to secure V104s onto
adapter. Use 15 in-lb torque
7. Insert each o-ring onto a plastic cap
8. Install plastic cap with o-ring onto V104s unit (rectangular notch
faced towards the outside)
9. Align and set the direction of V104s unit, while using the jam nut to
secure the unit (hand-tighten).
Over-tightening may damage the system. This is not covered
under warranty.
