Hendi 230442 - Page 12

12
EN
Mode Operation cycle Description
Inserve First water treatment
Backwash Second anti-current rinse
Brine & Slow Rinse Third regeneration with brine and slow
rinsing
Brine Refill Fourth filling the salt tank with water
Fast Rinse Fifth fast rinsing of the resin
8.2. CONTROL PANEL IN 230459 MODEL
# Funkcja Description
1 In serve water treatment, indicates water flow through the device;
2 Back wash regeneration reverse rinse of the resin;
3 Brine & slow rinse regeneration drawing of brine solution;
4 Brine refill filling water into the salt tank;
5 Fast rinse co-current rinse of the resin, brine rinse
6 clock indicates the current time;
