art.nr. 9606.041EN
User Manual
Vacuum Packaging Machines
T2, T3, T4, T5, T6 M1, M2, M3 M4, M5, M6 M7, M8 D1, D3, D4 D6
http: //www.henkovac.com
e-mail: info@henkovac.com
tel: +31736271201
SERIAL NUMBER
1ST CHOICE FOR PROFESSIONALS WORLDWIDE

Table of Contents

Questions and Answers

  • D
    Devin KingAug 5, 2025
    What to do if my Henkovac D1 machine does not work?
    • S
      Sarah GouldAug 5, 2025
      If your Henkovac Kitchen Appliance machine isn't working, there are several potential causes: * The machine might not be plugged into the electrical outlet. In this case, plug the machine into the electrical outlet. * The ground fault safety in the electrical panel may have tripped. Check the electrical panel. * A fuse in the electrical panel might be faulty. Check the electrical panel. * A fuse in the machine could be faulty. Consult your dealer. * The motor protection of the machine might be switched off. Consult your dealer.
  • R
    Randall MitchellAug 9, 2025
    Why is the seal leaking on my Henkovac D1?
    • T
      travis81Aug 9, 2025
      If the seal is leaking on your Henkovac Kitchen Appliances, it could be due to several reasons: * The package seam may be poorly formed. Try increasing the sealing time and/or reducing the MAP gas pressure. * The package seam might be burnt. Decrease the sealing time. * The opening of the vacuum bag could be contaminated. Try again, ensuring the bag opening stays clean. * The sealing beam might be dirty. Clean the sealing beam. * The Teflon lining of the sealing beam could be damaged. Replace the Teflon lining. * The silicon rubber seal in the counter beam might be damaged. Replace the silicon rubber seal.
  • E
    Erin FritzAug 14, 2025
    How to fix a Henkovac D1 machine that does not seal?
    • X
      xdoyleAug 14, 2025
      If your Henkovac Kitchen Appliances machine isn't sealing, consider these possibilities: * The bag isn't correctly positioned over the sealing beam. Adjust the bag position. * The sealing wire is broken. Replace the sealing wire. * The thermal safety of the power supply was tripped. Wait until the safety resets, which can take half an hour. Decrease the sealing time. * The electrical contacts of the seal beam have fouled. Remove the seal beam and clean the pins and contacts with sand paper.
  • M
    Michael MoodyAug 17, 2025
    What to do if the vacuum in the package is insufficient in Henkovac Kitchen Appliances?
    • J
      Jose MooreAug 18, 2025
      If the vacuum in the package is insufficient with your Henkovac Kitchen Appliances, it might be because: * The programmed vacuum value is too high. Lower the vacuum value in the program. * The packaging material is of poor quality. Select a better-quality packaging material. * The product damages the bag. Program a higher value for Soft-Air. * The machine gases the package. Turn off the gassing function.
  • M
    Mrs. Monique RomeroAug 22, 2025
    Why doesn't the vacuum pump run at full speed on my Henkovac Kitchen Appliances?
    • K
      Kevin JonesAug 22, 2025
      If the vacuum pump on your Henkovac Kitchen Appliances isn't running at full speed: * The oil might be too thick or contaminated. Consult your dealer. * The pump motor may be running on two phases. Consult your dealer.
  • C
    Catherine MejiaAug 27, 2025
    What causes not enough gas in the bag with Henkovac D1?
    • Z
      zmillerAug 27, 2025
      If there is not enough gas in the bag when using your Henkovac Kitchen Appliances, it could be due to: * The bag being too small. Select a bigger bag. * The programmed gas level being too low. Increase the gas level value. * The bag not being correctly positioned over the gas outlets. Adjust the bag position.
  • J
    Jesus NicholsAug 30, 2025
    How to reset the service symbol on Henkovac Kitchen Appliances?
    • M
      Michelle ParksAug 30, 2025
      To reset the service interval counters on your Henkovac Kitchen Appliances after an oil change: start the machine, and while the display shows the hours or cycles, press and hold the button.

Summary

Safety Regulations and Warnings

Intended Use of the Machine

Machine designed for commercial vacuum packaging of food or other products.

Safety Measures

Machine equipped with standard safety devices like overload protection and fan guards.

Welcome

General Precaution

Electrical grounding requirements and disconnecting power before servicing for safety.

Installation of Machine

Electrical Connection 3-phase vacuum pump

Steps to take if a 3-phase pump is incorrectly connected, causing noise.

Gas Connection for MAP Applications

Connecting gas supply for MAP, maximum pressure, cylinder securing, and ventilation.

Compressed Air Connection for Additional Sealing Pressure

Connecting compressed air for additional sealing pressure, max pressure, and model compatibility.

Digital Control with LCD Display

Operating the Machine with One-Program Control System

Entering the desired vacuum time

Adjusting vacuum time using +/- buttons and saving with the menu button.

Entering the desired sealing time

Adjusting sealing time using +/- buttons and saving with the menu button.

Ten-Program Control System

Time-Based Operation

Customer selects values for 9 programs (P1-P9) for time-controlled operation.

9 customizable programs (P1-P9)

System allows creation and customization of up to nine programs.

Optional installation of a Sensor or Soft-Air

Upgrading time-based to sensor-based operation or adding Soft-Air feature.

Program P H2 O for liquid products

Specific program for packaging liquid products, preventing boiling.

Sensor-Based Operation

Digital display of vacuum pressure in mbar or % for sensor-based operation.

Programmable Functions

List of functions that can be customized for programs P1-P9.

Optional installation of Soft-Air

Operating the Machine with Ten-Program Control System

Stop-function

Stops the machine, aerates the chamber, and cancels subsequent functions.

Adjust program values and turn functions ON;OFF

Adjusting function values, turning functions ON/OFF, and saving changes.

Programs 1 through 9

PA - Automatic

P Hâ‚‚O - Program

Programming the Machine

One-Program Control System

Standard control system for certain models, time-based operation.

Programming

Steps to turn on the machine and view factory settings for vacuum and seal time.

Reviewing Vacuum Time and Sealing Time

Displaying programmed vacuum and sealing times.

Adjusting Vacuum Time for P1

Adjusting vacuum time using +/- buttons and saving.

Adjusting Sealing Time for P1

Adjusting sealing time using +/- buttons and saving.

Reviewing Function Values for P1-P9

Programming and Adjusting Values for P1-P9

Turning Program Functions ON;OFF

Adjusting ON;OFF Function Values

Symbols in the Display

P Hâ‚‚O program

Program for liquid products to prevent boiling and evaporation.

SYMBOLS INDICATING PROGRESS OF THE PACKING CYCLE

Vacuum Process

Measurement of vacuum pressure, digitally or via analog gauge.

Standard Vacuum Pump Settings

One-Program Control System

Ten-Program Control System

Further Explanation of Packaging Concepts

Vacuum Plus

Adds seconds to vacuum process to allow air escape from porous products.

Sealing

Extra Sealing Pressure

Soft-Air

Multi-Cycle

Maintenance

General

Regular maintenance prevents malfunctions, prolongs life, and optimizes sanitary conditions.

Vacuum Pump

Proper maintenance of the vacuum pump is important for its protection.

Adding and Changing the Pump Oil

Seal Beams and Counter Beams

Aluminum;Stainless Steel Seal Beam

Aluminum T-Shaped Seal Beam

Applying Teflon Tape to Seal Beam

Replacing Silicone Rubber Seal of Counter Beam

Rubber Seal of Vacuum Chamber Cover

Malfunctions and Notifications

Trouble Shooting Check List

A list of common faults, possible causes, and remedies.

There is not enough gas in the bag

The machine does not seal

Henkovac D1 Specifications
