Henkovac D4 - User Manual

32 pages

Save Page as PDF

To Next Page

To Next Page

Loading...

art.nr. 9606.041EN

User Manual

Vacuum Packaging Machines

T2, T3, T4, T5, T6 M1, M2, M3 M4, M5, M6 M7, M8 D1, D3, D4 D6

http: //www.henkovac.com

e-mail: info@henkovac.com

tel: +31736271201

SERIAL NUMBER

1ST CHOICE FOR PROFESSIONALS WORLDWIDE

Table of Contents

Default Chapter2
Operating the Machine with One-Program Control System9
- Ten-Program Control System10
  - Time-Based Operation10
    - Option Sensor and Option Soft-Air Retrofit10
  - Sensor-Based Operation10
- Operating the Machine with Ten-Program Control System11
Programming the Machine13

Questions and Answers

T
Tracey JenningsAug 5, 2025
What to do if my Henkovac D4 Kitchen Appliances machine does not work?
- C
  Cody BoydAug 5, 2025
  If your Henkovac Kitchen Appliance machine isn't working, there are several potential causes: * The machine might not be plugged into the electrical outlet. In this case, plug the machine into the electrical outlet. * The ground fault safety in the electrical panel may have tripped. Check the electrical panel. * A fuse in the electrical panel might be faulty. Check the electrical panel. * A fuse in the machine could be faulty. Consult your dealer. * The motor protection of the machine might be switched off. Consult your dealer.
D
dickersonmarkAug 9, 2025
Why is the seal leaking on my Henkovac Kitchen Appliances?
- O
  Olivia RobinsonAug 9, 2025
  If the seal is leaking on your Henkovac Kitchen Appliances, it could be due to several reasons: * The package seam may be poorly formed. Try increasing the sealing time and/or reducing the MAP gas pressure. * The package seam might be burnt. Decrease the sealing time. * The opening of the vacuum bag could be contaminated. Try again, ensuring the bag opening stays clean. * The sealing beam might be dirty. Clean the sealing beam. * The Teflon lining of the sealing beam could be damaged. Replace the Teflon lining. * The silicon rubber seal in the counter beam might be damaged. Replace the silicon rubber seal.
S
shanewrightAug 13, 2025
How to fix a Henkovac D4 machine that does not seal?
- W
  William ClarkeAug 13, 2025
  If your Henkovac Kitchen Appliances machine isn't sealing, consider these possibilities: * The bag isn't correctly positioned over the sealing beam. Adjust the bag position. * The sealing wire is broken. Replace the sealing wire. * The thermal safety of the power supply was tripped. Wait until the safety resets, which can take half an hour. Decrease the sealing time. * The electrical contacts of the seal beam have fouled. Remove the seal beam and clean the pins and contacts with sand paper.
P
Pamela PetersenAug 18, 2025
What to do if the vacuum in the package is insufficient in Henkovac D4 Kitchen Appliances?
- C
  Cynthia PowellAug 18, 2025
  If the vacuum in the package is insufficient with your Henkovac Kitchen Appliances, it might be because: * The programmed vacuum value is too high. Lower the vacuum value in the program. * The packaging material is of poor quality. Select a better-quality packaging material. * The product damages the bag. Program a higher value for Soft-Air. * The machine gases the package. Turn off the gassing function.
G
Gabrielle MorrowAug 22, 2025
Why doesn't the vacuum pump run at full speed on my Henkovac Kitchen Appliances?
- M
  Mr. Mark ReeseAug 22, 2025
  If the vacuum pump on your Henkovac Kitchen Appliances isn't running at full speed: * The oil might be too thick or contaminated. Consult your dealer. * The pump motor may be running on two phases. Consult your dealer.
B
Brandon HendricksAug 27, 2025
What causes not enough gas in the bag with Henkovac D4?
- M
  Matthew HornAug 27, 2025
  If there is not enough gas in the bag when using your Henkovac Kitchen Appliances, it could be due to: * The bag being too small. Select a bigger bag. * The programmed gas level being too low. Increase the gas level value. * The bag not being correctly positioned over the gas outlets. Adjust the bag position.
M
Morgan MatthewsAug 31, 2025
How to reset the service symbol on Henkovac Kitchen Appliances?
- Z
  Zachary RobertsAug 31, 2025
  To reset the service interval counters on your Henkovac Kitchen Appliances after an oil change: start the machine, and while the display shows the hours or cycles, press and hold the button.

Summary

Safety Regulations and Warnings

General Safety and Usage

Covers manufacturer's disclaimer, user manual guidelines, and intended use.

Machine Labels and Safety Devices

Importance of labels and list of standard safety features.

Welcome

General Electrical Safety

Precautions for electrical grounding and servicing.

Installation of Machine

Installation and Setup

Digital Control with LCD Display

One-Program Control System

Operating the Machine with One-Program Control System

One-Program Operation and Controls

How to operate the machine, stop/reset functions, and adjust times.

Ten-Program Control System

Service Indicator and Operation Modes

Ten-Program Stop Functions

Operating the Machine with Ten-Program Control System

Ten-Program Operation and Controls

How to operate, control functions, and navigate the system.

Programming and Adjusting Values

Steps to review, adjust, and save program values and functions.

Programming the Machine

One-Program Control System Programming

Details on programming P1 vacuum and sealing times.

Ten-Program Control System

Ten-Program System Overview and Functions

Overview of customizable programs (P1-P9), PA, PH2O and programmable functions.

Reviewing and Adjusting Program Values

Steps to review, program, and adjust values for P1-P9.

Managing Program Functions (ON;OFF)

How to enable/disable and adjust values of specific functions.

Turning Off the Ten-Program Machine

Symbols in the Display

Display Symbol Overview

Symbols Indicating Progress of the Packing Cycle

Cycle Progress Indicators

One-Program Control System

One-Program Stop Functions

Further Explanation of Packaging Concepts

Sensor-Based and Time-Based Control

Sealing

Sealing Methods Explained

Describes single seal, double seal, clean cut, CCC seal, and two-sided seal.

Soft-Air

Soft-Air Functionality

Cool-Down;Oil Dehumidification

Vacuum Pump Cool-Down

Maintenance

General Maintenance Guidelines

Vacuum Pump Maintenance

Tasks for maintaining the vacuum pump, including cleaning vents and checking oil.

Adding and Changing the Pump Oil

Pump Oil Handling and Replacement

Procedures for adding and changing pump oil, including recommended types.

Seal Beams and Counter Beams

Seal Beam Maintenance

Single-Seal Beam Procedures

Aluminum;Stainless Steel Seal Beam

Aluminum;Steel Seal Beam Procedures

Aluminum T-Shaped Seal Beam

T-Shaped Seal Beam Procedures

Trouble Shooting Check List

Fault Diagnosis and Remedies

A list of common faults, their causes, and suggested remedies.

Recommended Spare Parts

Spare Parts Catalog

Henkovac D4 Specifications
