14.0 Utilities
Electrical
Voltage, current, frequency
See identification plate
Maximum voltage tolerance
- 10% to + 10%
Gas (optional)
Maximum allowable pressure
1 bar
Composition
No explosive , corrosive, caustic and/or contami-
nated gases
Connection
Hose coupling, 8mm for compressed air /
10mm for MAP gas
External sealing pressure (optional)
Maximum allowable pressure
1 bar
Composition
Clean, dry compressed air
Connection
Hose coupling, 8mm
14.1 General Data
Recommended Oil Types
DIN 51506
Pumps
HLPT 22
4m
3
VG032
8m
3
- 16m
3
- 21m
3
1-phase pump
VG068
40m
3
- 63m
3
1-phase pump
VG 100
40m
3
- 300m
3
3-phase pump
Ambient Conditions
Ambient temperature
+ 5 to + 30° C / 41 to + 86° F
Transport temperature
- 25 to + 55° C / - 13° F to + 131° F
Positioning
Inside, level, unobstructed
15.0 Commonly-Used Symbols
The following pictograms and symbols are applied to your machine:
WARNING
First consult the user manual regarding:
 Connecting the gas
 Connecting the compressed air
WARNING
 Risk for electric shock; before opening, remove the plug from the outlet
 Access by certified personnel only
Connection for compressed air
Connection for MAP gas
