Charging poor
Start engine to check voltage among
terminals of battery
High voltage
Voltage in normal
Rectifier
Battery aging
Voltage not boost
Bad battery
Check ACG charging coil resistance Bad starter
Normal range
Out of range Yellow wiring broken
Connection poor
Check voltage of red and green wiring on
rectifier connector
No voltage
Wire broken
Battery with voltage
Remove rectifier connector and check each
device
Normal
Bad rectifier
Abnormal Plunger defect
Check ACG coil resistance value
Normal
Wire broken
Abnormal
AC Generator defect
