2-1
2. CHECK AND ADJUST
Way of Check and Service……………………2-1
Disassembly of External Parts………………..2-3
Layout of Maintenance Items…………………2-6
Way of Check & Adjustment
1. Mark “○” is checking time.
2. Mark “☆” is the regular exchange of service items.
This exchange time is just for general riding of the majority not for the special use, please arrange with
this principle according to the difference of the riding condition.
Service Time (month)
Service Items
Before
riding
1st each 6 each 12
Judgement Standard Remarks
Operating Device
Handle- Play, loose/tight
Operation
○
○
Wheels- Right/left turn round angle
○
Front Fork-Damage
Installation of shaft
Shaft Gap
○
○
○
○
○
Direction Post
Direction Post
Brake Device
Brake- Play
Try to run
Correct brake
○
○ ○
○
○
○
○
○
○
Play of
b
rake lever
10-20 mm
Wires- Loose / tight and damage
○ ○ ○
Gap of casing & brake
○ ○
Wore of brake & operating parts
○
Direction
Wore & Damage of casing
○
Standard diameter 110 mm
Limitation 110.5mm
Riding Device
front rear
Air pressure 1.50 kg/cm
2
1.75 kg/cm
2
Tires-Air pressure of tires
○ ○ ○
tire 120/90-10 130/90-10
