HER CHEE GTC-50 - Page 24

ADLY MOTO
2-6
Tail light assembly
* Remove 2 hex bolts and rear fender
assembly.
* Remove the left and right body covers.
* Remove 2 hex bolts and the tail light
assembly.
* Follow the mounting sequence in
reverse order.
＊ATTENTION ：
- Match the rear guard holes and the
convex of the chassis.
Adjustment of the head light
* Adjustment of the beam of the head
light is by loosening the screw
underneath the head light
