Page 8 Item 56932
Warning Symbols and Definitions
Specifications
Electrical Rating 120 VAC / 60 Hz / 4 A
No Load Speed n
25,000/min
Max. Accessory Diameter 1-1/2″ (38 mm)
Collet Hole Diameter 1/4″
SET UP - BEFORE USE
Functional Description
1
3
1. Power Switch
2. Collet Nut
3. Spindle
OPERATING INSTRUCTIONS
Tool Set Up
Installing Accessories
1. The accessory MUST be:
• Rated to at least 25,000 RPM.
• No larger than 1-1/2″ (38 mm) in diameter.
• Fitted with a 1/4″ mandrel.
• Undamaged.
• An abrasive cut‑off wheel, sander,
polisher, wire brush or grinding wheel
(accessories not included).
2. Hold Spindle with included Small
Wrench, while turning Collet Nut with
included Large Wrench to loosen.
3. Insert accessory’s mandrel into Collet at least 5/8″.
4. Using the Wrenches, securely tighten the Collet.
Workpiece and Work Area Set Up
1. Designate a work area that is clean and well‑lit.
The work area must not allow access by children
or pets to prevent distraction and injury.
2. Route the power cord along a safe route
to reach the work area without creating a
tripping hazard or exposing the power cord to
possible damage. The power cord must
reach the work area with enough extra length
to allow free movement while working.
3. Secure loose workpieces using a vise or clamps
(not included) to prevent movement while working.
4. There must not be hazardous objects, such
as utility lines or foreign objects, nearby
that will present a hazard while working.
5. You must use personal safety equipment including,
but not limited to, ANSI‑approved eye and hearing
protection, as well as heavy‑duty work gloves.
