Page 8 M6#(/'.N0$."&(O3'-/$60-F(*&'"-'(."&&(;4PPP4PQQ4RSTSK Item 56214
PARTS LIST AND DIAGRAM
Parts List
Y"#/ W'-.#$*/$60 k/E
1 Release Lever 1
2 Cam 1
3 Screw 3
4 Cylindrical Pin 1
5 Spanner Base 1
6 Hot Board 1
7 Spindle 1
8 Connector 1
9 Compression Spring 1
10 Washer 1
11 Orientation Sleeve 1
12 Compression Spring 2
13 Clutch Lining 1
14 Shaft 1
15 O Ring 1
18 Left/Right Cover 1
19 Screw 3
20 Retaining Ring 1
21 Ball Bearing 619 1
22 Screw 4
23 Fore Housing 1
24 Light Socket 1
25 Light Cover 1
26 Shaft Cover 1
27 Ball Bearing 618 1
30 Spring Board 1
32 Power Supply Board 1
33 Pendulum Fork 1
34 Retaining Ring 1
35 Ball Bearing 607 1
36 Washer 1
37 Counterweight Piece 1
Y"#/ W'-.#$*/$60 k/E
38 O Ring 1
39 Middle cover 1
41 Rotor Set 1
42 Dust Proof Ring 1
44 Magnet Ring 1
45 Wind Baffle Ring 1
46 Screw 2
47 Stator Set 1
48 Trigger 1
49 Switch Lever 1
50 Housing 1
51 O Ring 1
52 Retaining Ring 1
53 Brush Bracket Assembly 1
54 Self-Tapping Screw 2
55 Carbon Brush 1
56 Constant Speed Assembly 1
57 Screw 1
58 Rear Cover 1
59 Rubber Pin 2
60 Self-Tapping Screw 2
61 Screw 3X6 2
62 Brush Bracket I Assembly 1
63 Speed Adjustment Knob 1
64 Power Cord 1
68 Sanding Pad 1
101 Lever Assembly 1
102 Output Shaft Assembly 1
103 Flange Assembly 1
104 Rotor Assembly 1
105 Housing Assembly 1
