HERO SPLENDOR PRO - Description; Parts Location

19
12
(2) Front turn signal lamp
(7) Dimmer switch
(8) Speedometer
(3) Horn switch
(1) Turn signal indicator
(6) Passing switch
(4) Turn signal switch
(5) Headlamp switch
(10) Neutral indicator
(9) Odometer
(15) Front brake lever
(13) Side stand indicator
(17) Electric starter switch
(16) Throttle grip
(18) Ignition switch with steering lock
(12) High beam indicator
(14) Rear view mirror
(11) Fuel gauge
(19) Leg guard
(20) Fuel tank lid
7
17
18
3
2
1
4
8 13 14
20
DESCRIPTION
5
6
9
10 11
15
16
