HERO SPLENDOR PRO - Left Side View

2
14
(1) Fuel valve
(4) Rider foot rest
(5) Main stand
(3) Gear shift pedal
(2) Carburetor
(6) Side stand switch
(7) Side stand
(9) Women pillion step
(8) Pillion foot rest
(10) Saree guard
(11) Reflex reflector
(12) Rear number plate
(14) Rear carrier
(13) Tail/Stop lamp
(15) Helmet lock
(16) Left side cover
(17) Air suction valve
(18) Clutch lever
(19) Front number plate
3
6 7 8 9
11
12
13
151617
19
LEFT SIDE VIEW
4 5
10
1
18
