49
Axle nut torque : 5.4 kgf-m
(page 40 & 41).
Remove the axle nut (8) and pull out
the axle (9). Remove the wheel.
Adjust the brake (page 41 & 42) and
drive chain (page 38 ). to 40
Brake stopper arm nut torque : 2.2 kgf-m
Axle nut torque : 5.4 kgf-m
brake pedal. Disconnect the brake
stopper arm (4) from the brake panel (5)
by removing split pin (6) and nut (7).
Lock nut
Brake stopper arm
To Next Page
