HCP 5D
Power Supply
Power supply voltage / fuse: 11÷15 VDC / 2 x 25 A
Idling current (power ON/OFF): 2 A / 0.04 mA
Consumption @ 2Ω, 14.4 VDC
(Max Musical Power):
30 A
Remote In: 7 ÷ 15 VDC - 1 mA
ART: Automatic Remote Turn-On/Off with Speaker-In
Inputs / Outputs / Filter
INPUTS: PRE IN / SPEAKER IN
FRONT Ch. filters FULL
: Yes
Hi-Pass: 50 ÷ 5k Hz @ 12 dB/Oct.
REAR Ch. filters FULL
: Yes
Hi-Pass: 50 ÷ 500 Hz @ 12 dB/Oct.
Band-Pass: 50 ÷ 500 Hz (hi) @ 12 dB/Oct.
50 ÷ 5kHz (lo) @ 12 dB/Oct.
SUB Ch. filter LO-PASS: 50 ÷ 500 Hz @ 24 dB/Oct.
SUBSONIC (on/off): 25 Hz @ 24 dB/Oct.
BOOST 50 Hz (adjust): (0 ÷ 12) dB
Remote Volume Control (adjust): (-50 ÷ 6) dB
Size / Weight
Max size (mm / in.): 345 x 190 x 50 / 13.58” x 7.48” x 1.97”
Weight (kg / lb.): 2,61 / 5.75
Output Power (RMS) @ 14.4 VDC, THD 1%:
5 Ch: 55 W x 4 + 160 W x 1 (4Ω)
5 Ch: 90 W x 4 + 280 W x 1 (2Ω)
3 Ch: 180 W x 2 (4Ω) + 160 W x 1 (4Ω)
3 Ch: 180 W x 2 (4Ω) + 280 W x 1 (2Ω)
Output Power (RMS) @ 14.4 VDC, THD 10%:
5 Ch: 65 W x 4 + 200 W x 1 (4Ω)
5 Ch: 105 W x 4 + 330 W x 1 (2Ω)
3 Ch: 210 W x 2 (4Ω) + 200 W x 1 (4Ω)
3 Ch: 210 W x 2 (4Ω) + 330 W x 1 (2Ω)
CEA 2006-A Ratings:
RMS Power (4Ω
,≤1 %THD+N, 14.4 V):
50 W x 4 Ch + 150 W + 1 Ch
S/N Ratio (ref. 1 W output):
(50 W Ch) 83 dBA
(150 W Ch) 83 dBA
Amplifier Stage
Features:
Distorsion - THD (100 Hz @ 4Ω): 0.02 %
Bandwidth FRONT/REAR: 10 ÷ 50k Hz
Bandwidth SUB: 10 ÷ 500 Hz
S/N Ratio (A weighted @ 1 V): 100 dB
Damping factor (100 Hz @ 4Ω) FRONT/REAR: 100
Damping factor (100 Hz @ 4Ω) SUB: 250
Pre-In sensitivity: 0.6 ÷ 5 VRMS (15 kΩ)
Speaker-In sensitivity: 1.5 ÷ 12 VRMS (47Ω)
Load impedance (MIN) @ 5 Ch: 2Ω
@ 3 Ch: 4Ω + 4Ω + 2Ω
