Hertz AMPLIFIER - Installation and Sizes; Amplifier Dimensions and Models; Cable Size Calculation Tables; Power Supply Cable Sizing

Advanced Web Manual
HCP
4
215 200 190 166 50 mm
8.46 7.87 7.48 6.53 1.97 in.
215 200 190 166 50 mm
8.46 7.87 7.48 6.53 1.97 in.
315 291 190 166 50 mm
12.40 11.45 7.48 6.53 1.97 in.
215 200 190 166 50 mm
8.46 7.87 7.48 6.53 1.97 in.
Applied power Cable diameter
Connection length
*Current Draw I (A)
Cable Length (m)
A B C D E
345 321 190 166 50 mm
13.58 12.64 7.48 6.53 1.97 in.
HCP 1D
HCP 2
HCP 4
HCP 4D
HCP 5D
1: Power supply cable
2: Speakers cable
B
D
C
E
A
2 INSTALLATION AND SIZES
3 CABLE SIZE CALCULATION TABLES:
1: Power supply cable / 2: Speakers cable
