Hertz HCP 2 - 4. POWER SUPPLY AND REMOTE IN CONNECTION; FUSE REPLACEMENT; Fuse Replacement and Power Connections

Quick Start Guide
33
OPTIONAL
HRC
HCP 1D
GND REM FUSE+12V
20
FUSE REPLACE WARNING:
firmly press contacts of each
fuse into their fuse-holder clips
APPLY A FUSE CLOSE
TO BATTERY POSITIVE POLE
TO PROTECT BATTERY CABLE
AMPLIFIER FUSE
(see Tech. Spec.)
REMOTE OUT
SOURCE
POWER
CAR BATTERY
FUSE
GND
GND
4. POWER SUPPLY and REMOTE IN CONNECTION /FUSE REPLACEMENT
5. SUBWOOFER REMOTE VOLUME CONTROL: HRC INSTALLATION
SUBWOOFER
REMOTE VOLUME CONTROL
HRC
OPTIONAL
HCP 5D
SUBWOOFER
REMOTE VOLUME CONTROL
POWER SUPPLY
16 mm / 0.62 in.
REMOTE
12 mm / 0.47 in.
Adjustment
CONTROLS
Not
AVAILABLE
::
Set-up
CONTROLS
:
