16
1.19 Parts Inspire 45-45H Stove
Pos. No. Name Qty.
1 5013-0008 Handle 1
2 5013-0009 Set of glass clips 1
3 0021-0053 Glass 1
4 4005-0042 Door, with glass tape 1
5 0008-9086 Hinge Pin 2
6 0023-3013 Glass seal 3x8 mm 1.3 m
7 0023-3008 Door seal ø12 1.72 m
8 0023-3008 Door seal ø12 0,4 m
9 1020-0001 Handle for ash pan 1
10 1518-0091 Ash pan 1
11 0030-0020 Shaking grate 1
Pos. No. Name Qty.
12 0030-0201 Shaking grate, Ø195 mm 1
13 0015-2013 Shaking grate handle 1
14 1019-0026 Log retainer 1
15 0023-0150 Baffle plate 1
16 0023-0153 Left stone 1
17 0023-0152 Right stone 1
18 0023-0177 Left back stone 1
19 0023-0178 Right back stone 1
20 0023-0154 Bottom stone 2
21 5032-0026 Flue collar set 1
4 -
- 5 x2
7-
6 -
- 1
-9
3 -
-2 x4
-14
- 11
- 21
- 10
13 -
15 -
16 -
18 -
- 20 -
19 -
- 17
12-
8 -
